prius II

Prius II 1.8L 4-Cyl. Hybrid

PRICE
About $22,800

MECHANICAL
Gasoline Engine
Type
Aluminum double overhead cam (DOHC) 16-valve VVT-i 4-cylinder standard
Displacement
1.8 liters (1798 cc) standard
Bore x stroke
3.17 in. x 3.48 in. standard
Compression ratio
13.0:1 standard
Valvetrain
Four valves per cylinder with Variable Valve Timing with intelligence (VVT-i) standard
Induction system
Sequential multi-point EFI with Electronic Throttle Control System with intelligence (ETCS-i) standard
Ignition system
Electronic, with Toyota Direct Ignition (TDI) standard
Power output
98 hp @ 5200 rpm (73 kW @ 5200 rpm) standard
Torque
105 lb.-ft. @ 4000 rpm (142 N•m @ 4000 rpm) standard
Emission rating
Advanced Technology Partial Zero Emission Vehicle (AT-PZEV) [1] standard
Electric Motor
Motor type
Permanent magnet AC synchronous motor standard
Power output
80 hp (60 kW) standard
Torque
153 lb.-ft. (207 N•m) standard
Voltage
650V maximum standard
Traction Battery
Type
Sealed Nickel-Metal Hydride (Ni-MH) [2] standard
Power Output
36 hp (27 kW) standard
Voltage
201.6V standard
Hybrid System Net Power
134 hp (100 kW) standard
Mechanical/Performance
Transmission
Electronically controlled continuously variable transmission (ECVT) standard
EV mode [3] standard
Eco and Power modes standard
Front Suspension
Independent MacPherson strut with stabilizer bar standard
Rear Suspension
Torsion beam standard
Steering
Electric Power Steering (EPS); rack-and-pinion with electric power-assist standard
Turning circle diameter, curb to curb (ft.) 34.2
Brakes
Power-assisted ventilated front disc, solid rear disc with Anti-lock Brake System (ABS) and integrated regenerative braking standard
Coefficient of drag (Cd) 0.25

DIMENSIONS
Exterior Dimensions (in.)
Overall height/width/length 58.7/68.7/175.6
Wheelbase 106.3
Track (front/rear) 60.0/59.8
Minimum running ground clearance 5.5
Interior Dimensions, front/rear (in.)
Head room 38.6/37.6
Shoulder room 54.9/53.1
Hip room 52.7/51.2
Leg room 42.5/36.0

WEIGHTS AND CAPACITIES
Curb weight (lb.) 3042
Seating capacity 5
Passenger volume (cu. ft.) 93.7
Luggage capacity (cu. ft.) 21.6
Fuel tank (gal.) 11.9

TIRES
Size
P195/65R15 standard
P215/45R17 not available
Spare
Temporary standard

MPG
Mileage estimates (mpg city/highway/combined) [4] 51/48/50

EXTERIOR
LED (light-emitting diode) headlamps with auto leveling, auto-off and headlamp washers not available
Integrated fog lamps
LED taillamps standard
Color-keyed foldable power outside mirrors standard
Heated outside mirrors standard
Hybrid Synergy Drive® blue accent badges and headlamps standard
15-in. 5-spoke alloy wheels with P195/65R15 tires and wheel covers standard
17-in. 5-spoke alloy wheels with P215/45R17 tires not available
Washer-linked variable front intermittent wipers standard
Rear window with electric defogger with timer standard
Intermittent rear window wiper standard
UV reduction glass windshield standard
Driver and front passenger water-repellent side windows not available
Aerodynamic rear deck spoiler standard
Power tilt/slide moonroof with Solar Powered Ventilation System [1] and Remote Air Conditioning System [2] not available
Roof-mounted XM Satellite Radio [3] antenna standard

INTERIOR
CFC-free automatic climate control with electric compressor, dust and pollen filtration mode, humidity sensor and air filter standard
Plasmacluster™ [4] ionizer not available
AM/FM/MP3 CD player with six speakers and satellite radio capability [3] standard
JBL® AM/FM/MP3 6-disc CD changer with eight speakers, integrated satellite radio capability [3] and hands-free phone capability via Bluetooth® [5] wireless technology not available
Voice-activated touch-screen DVD navigation system [6] with JBL® AM/FM/MP3 4-disc CD changer, eight speakers, USB [7] port with iPod® [8] connectivity, integrated satellite radio capability, XM NavTraffic® [6] [9] capability, hands-free phone capability and music streaming via Bluetooth® [5] wireless technology, and integrated backup camera [10] not available
Auxiliary audio jack standard
Power windows with auto up/down, jam protection in all positions and retained-power features standard
Power automatic door locks with anti-lockout feature standard
Smart Key System [11] on driver's door and remote illuminated entry standard
Remote keyless entry system with Push Button Start, 2-stage unlocking and panic function standard
Fabric-trimmed seats and door panels with storage pockets and bottle holders in front doors standard
Leather-trimmed seats and steering wheel with driver seat power lumbar support and heated front seats with bottle holders in front doors not available
6-way adjustable driver's seat and 4-way adjustable passenger seat with adjustable headrests standard
Driver seatback pocket standard
Front passenger seatback pocket standard
60/40 split fold-down rear bench seat with adjustable headrests standard
Fold-forward rear outboard headrests standard
Rear fold-down armrest with two cup holders standard
Tilt/telescopic adjustable steering wheel with audio, climate and Multi-Information Display controls [12] standard
Steering wheel-mounted Dynamic Radar Cruise Control (DRCC) [13] and Lane Keep Assist (LKA) [14] controls [12] not available
Steering wheel-mounted Bluetooth® [5] hands-free phone-calling controls not available
Cruise control standard
Dynamic Radar Cruise Control (DRCC) [13] not available
Intelligent Parking Assist (IPA) [15] not available
Central instrument display with digital speedometer, instant fuel consumption, fuel gauge and shift-lever indicator standard
Multi-Information Display with energy monitor, fuel consumption history, Hybrid System Indicator, odometer with twin tripmeters and cruise information (average fuel economy, average speed and distance to empty) standard
Touch Tracer Display standard
Overhead console with maplights and shift illumination standard
Electronic shift lever with Hybrid Synergy Drive® blue accent standard
EV mode [16] standard
Eco/Power modes standard
Auto-dimming rearview mirror with HomeLink® [17] universal transceiver not available
Dual sun visors and illuminated vanity mirrors standard
Center-console with sliding armrest and storage compartment with removable utility tray, wire-management feature and dual front cup holders standard
Dual-compartment glove box standard
Remote hood and fuel-filler door releases standard
Rear dome lights and cargo area lamp standard
Retractable assist grips at all doors standard
Two 12V auxiliary power outlets standard
Cargo area side-panel storage and under-floor storage standard
Tonneau cover with clasp for under-floor stowage standard

SAFETY
Star Safety System™ - includes Enhanced Vehicle Stability Control (VSC) [18] + Traction Control (TRAC), Anti-lock Brake System (ABS) with Electronic Brake-force Distribution (EBD) and Brake Assist [19] standard
Safety Connect™ [20] not available
Pre-Collision System (PCS) [21] not available
Lane Keep Assist (LKA) [14] not available
Driver and front passenger Advanced Airbag System [22] standard
Driver and front passenger front seat-mounted side airbags and front and rear side curtain airbags [22] standard
Driver's knee airbag [22] standard
Driver and front passenger active headrests [23] standard
Direct Tire Pressure Monitor System (TPMS) [24] standard
Front and rear energy-absorbing crumple zones standard
Side-impact door beams standard
Driver and front passenger seatbelt warning sensor standard
3-point seatbelts in all seating positions standard
Adjustable seatbelt anchors for front seating positions standard
Emergency Locking Retractor (ELR) on driver's belt, Automatic/Emergency Locking Retractor (ALR/ELR) on all passenger belts standard
Front seatbelt pretensioners with force limiters standard
LATCH (Lower Anchors and Tethers for Children) for outboard rear seating positions only standard
Child-protector rear door locks standard
Hill Start Assist Control (HAC) [25] standard
Collapsible steering column standard
Engine immobilizer [26] standard
Center high-mount stop lamp (CHMSL) standard
Temporary spare tire standard

Source: http://www.toyota.com/
Image: http://www.examiner.com/
